CONVENTIONAL
LIGHTNING
PROTECTION SYSTEM
Protect Your Infrastructure from Lightning Risk
Ensure complete safety for your buildings with advanced lightning protection systems designed as per international standards. Our solutions are engineered to safely intercept, conduct, and disperse lightning energy without damage.
LIGHTNING ARRESTER
We undertake design, supply, and installation of lightning protection systems in compliance with international standards
IEM - 62305
NFPA - 780
BS- EN-62305
IS - 2309
This ensures the correct placement of air termination systems on the structure. Down conductors are strategically positioned to provide the most direct path from the air terminal to a low-impedance grounding system, ensuring safe
and effective dissipation of lightning current. Equipotential bonding of all conductive systems is essential to reduce ground potential differences and minimize damage caused by lightning impulses.
Standard Complient
Expert Engineer
Reliable Protection
Customized Solution
KEY COMPONENTS
Air Terminal With multi-point
Captures lightning strikes at the highest exposed point of the structure.
Air Terminal Base
Provides stable support and secure mounting for the air terminal.
Square Clamp
Ensures strong mechanical connection between terminal components.
Our Convential Lightning Protection System is built with high- quality components that work together to ensure reliable protection and safe lightning dissipation
DC Tape Clip
Secures conductor routing across structural surfaces.
Oblong Test Clamp
Allows easy testing and maintenance of grounding continuity.
Earthing Rod
Transfers lightning energy safely into the ground.
Copper / G.I Mesh
Distributes lightning energy across the roof protection network.
Down Conductor
Safely channels lightning current from the terminal to the grounding system.
Bonding to Staircase
Connects metallic structural elements to maintain equipotential bonding.
SPECIFICATIONS TABLE
Multi - Point Air Termial
Model
Length (mm)
Rod Dia (mm)
Material
Aphere Size (mm)
SMI-FR60
1200
25.4
Copper
60
SMI-FR80
1200
25.4
Copper
60
SMI-FR100
1200
25.4
Copper
100
SMI-FR1612
1200
16
Copper
-
SMI-FR1615
1200
16
Copper
-
MATERIAL SPECIFICATION
Taper Pointed Air Rods
The air termination network forms the primary point of contact for lightning strikes within the protection system. These systems can be configured with or without multi-point air terminals. However, research and field studies indicate that multiple-point taper air rods provide more effective lightning interception than conventional single taper rods.
The taper pointed air rods lightning arrester feature a precision taper of less than 5 degrees on one end, ensuring a secure fit with multi-point assemblies. The opposite end is threaded for easy integration with terminal bases, flat saddles, ridge saddles, air rod bases, rod brackets, and air rod couplings.
